Running Distance
Up to 30-40 miles
Max Forward Speed
Up to 25mph
Max Grade
Up to 25%
Batteries
Lifepo4 (Lithium Iron Phosphate 4)
52.1v 120ah, 52.1v 160ah, 72v 200ah
Brakes
2 Front Hydraulic Disc
2 Rear Hydraulic Drum
Turning Radius
9'
Wheels
12 or 14 inch wheels
Max Load Capacity
800 lbs
Dimensions
7.8ft x 4.4ft x 6.1ft
Top Tier Carts X2R
To add additional accessories when building your golf cart, please visit our Accessories page.
Interested in building the cart of your dreams, exactly the way you want it? We've got you covered!
Top Tier Carts will be with you every step of the way! Providing pictures of each step in the build process.
- Steel chassis and wiring
- Body paint, assembly and seats
- Wheels/Tires
- Accessories
The build process only takes 60-75 days from the time you make your first deposit! Contact us to learn more.
1 year warranty on all non-wearable parts. Labor is not covered. (see contract agreement)
Performance
Battery Options: Lithium 51.2 105ah, 51.2 120ah, 51.2 160ah, 72v 200ah
Motor Options: 5kw, and 7.5kw (w/72v 200ah battery)
Controller: FJ
Range: 30-40 miles
Minimum turning radius: 9.85 feet
Max climbing radius@ 12.49: 1 gear ratio: 25%
Max loading weight: 705lbs
Net weight: 770lbs (without battery)Dimensions
Overall dimensions: 7.8ft x 4.4ft x 6.1ft
Min ground clearance: .78ftBody and Frame
Frame: Welded steel framework with phosphate plus powder coated treatment.
Body: PP Plastic front body and PP Plastic rear body
Roof: Fiberglass
Dashboard: forward/ reverse switch, battery capacity indicator, ignition key
Touch Screen with Apple/ Android Car Play.
Glove Boxes: 1 on each side
Electric System
Lighting System and Horn: All LED lights, 2 headlights (Full Headlight and Daytime running light option), 2 front turn signals, 2 tail lights, 1 horn
Digital Meter: speed, mileage, headlight indicator, emergency light indicator (hazards), turn signal indicator, reverse indicator.
Steering and Suspension
Steering System: Single-stage rack and pinion steering system, automatic rocker compensating function.
Brake System: 4-wheel hydraulic brake front disc and rear drum brakes
Accelerator: Stepless speed change
Suspension: Front independent and rear plate spring plus vibration absorber
Driving mode: Rear axle two stage deceleration, motor direct driving
Rear axle: Integrated, Gear ration 12 49: 1
Wheel and Tire: 12 and14 inch wheel options. Street tread, or off-road tire options.
